Principais benefícios
- Rugged series in corrosion-resistant metal housing
- IO-Link interface for service and process data
- Extremely high switching frequency
- Clear and functional display concept for the operating modes
- Resistant against noise: reliable operation under all conditions
- Aluminum housing with high quality Delta-Seal coated
| Effective detection range | 0 … 8 m |
| Reflector distance | 0.1 … 8 m |
| Threshold detection range | 10 m |
| Reference target | H85-2 reflector |
| Light source | LED |
| Light type | modulated visible red light , 625 nm |
| Polarization filter | yes |
| Angle deviation | max. ± 1.5 ° |
| Diameter of the light spot | approx. 300 mm at detection range 8.5 m |
| Opening angle | 1.5 ° |
| Optical face | frontal |
| Ambient light limit | 20000 Lux |
