Principais benefícios
- Rugged series in corrosion-resistant metal housing
- Reliable recognition of reflective objects and clear glass
- Two machines in one: clear object detection or reflection operating mode with long range
- IO-Link interface for service and process data
- Teach-in switch for setting the contrast detection levels
- Resistant against noise: reliable operation under all conditions
| Effective detection range | 0 … 4 m in TEACH mode 0 … 5.2 m at switch position “N” |
| Reflector distance | 0 … 4 m in TEACH mode 0 … 5.2 m at switch position “N” |
| Threshold detection range | 6.5 m |
| Reference target | H85-2 reflector |
| Light source | LED |
| Light type | modulated visible red light , 660 nm |
| Polarization filter | yes |
| Angle deviation | max. ± 1° |
| Diameter of the light spot | approx. 100 mm at detection range 4 m |
| Opening angle | 1.5 ° |
| Optical face | frontal |
| Ambient light limit | 40000 Lux |
