Principais benefícios
- CANopen interface
- Sensing range up to 25 m
- Degree of protection IP68 / IP69
- High EMC resistance
- Sensor head bidirectional and rotatable
- Robust metall fastening
| Measuring technology | FMCW |
| Measuring range | |
| Dead band | 0 … 0.5 m |
| Standard target plate | corner reflector 100 mm edge length |
| Working frequency | 122.25 … 123 GHz |
| Opening angle | < 12 ° (see characteristic curve) |
| Transmitter radiated power (EIRP) | < +20 dBm |
| Sampling rate | 1 … 200 Hz , programmable |
