Principais benefícios
- Sensor head bidirectional and rotatable
- NO/NC selectable
- Metal base with ground connection
| Switching function | Normally open/closed (NO/NC) |
| Output type | Two-wire |
| Rated operating distance | 20 mm |
| Installation | flush |
| Output polarity | AC/DC |
| Assured operating distance | 0 … 16.2 mm |
| Actual operating distance | 18 … 22 mm |
| Reduction factor rAl | 0.4 |
| Reduction factor rCu | 0.3 |
| Reduction factor r304 | 0.77 |
| Reduction factor rFe | 1 |
| Reduction factor rBrass | 0.43 |
| Output type | 2-wire |
