Principais benefícios
- Sensor head bidirectional and rotatable
- 20 mm flush
- E1-Type approval
- Extended temperature range
-40 … +85 °C - 4 LEDs indicator for 360° visibility
| Switching function | complementary |
| Output type | PNP |
| Rated operating distance | 20 mm |
| Installation | flush |
| Output polarity | DC |
| Assured operating distance | 0 … 16.2 mm |
| Actual operating distance | 18 … 22 mm typ. 20 mm |
| Reduction factor rAl | 0.34 |
| Reduction factor rCu | 0.32 |
| Reduction factor r304 | 0.77 |
| Reduction factor rSt37 | 1 |
| Reduction factor rBrass | 0.43 |
| Output type | 4-wire |
