Principais benefícios
- Miniature design
- Easy to use
- Very bright, highly visible light spot
- Full metal thread mounting
- Highly visible LEDs for Power ON and switching state
- Not sensitive to ambient light
| Detection range | 5 … 350 mm |
| Detection range min. | 5 … 30 mm |
| Detection range max. | 5 … 350 mm |
| Adjustment range | 30 … 350 mm |
| Reference target | standard white, 100 mm x 100 mm |
| Light source | LED |
| Light type | modulated visible red light |
| Polarization filter | no |
| Black-white difference (6 %/90 %) | < 18 % at 350 mm |
| Diameter of the light spot | approx. 20 mm at a distance of 350 mm |
| Opening angle | approx. 4 ° |
| Optical face | frontal |
| Ambient light limit | EN 60947-5-2:2007+A1:2012 |
